Miller Multimatic® 255 Multiprocess Welder w/EZ-Latch™ Single Cylinder Running Gear 951767
The Miller Multimatic® 255 multi-process welder with EZ-Latch™ single cylinder running gear is a 350 amp, portable welder that is capable of MIG, Pulsed MIG, Stick, DC TIG and DC Pulsed TIG welding. The Multimatic® 255 comes complete with full color seven inch LCD screen with Auto-Set™ Elite technology. Auto-Set™ Elite sets MIG, Stick and TIG welding parameters automatically, all you need to do is enter metal thickness and welding wire or tungsten electrode diameter. In addition to built-in welding programs, the 255 can also store your custom welding programs. It seamlessly switches between welding with standard MIG gun or optional Spoolmatic™ spool gun. The 255 also features direct plug for XR push-pull gun for professional aluminum wire feed capability. This allows you to use 12 inch spools of aluminum MIG wire instead of the more expensive 1 lb rolls used with the spool gun.
EZ-Latch™ running gear with single cylinder cylinder rack gives unmatched portability to the Multimatic 255. For moving around the shop, the 255 attaches to the running gear through a series of four, quick-disconnect latches. For times when your 255 is taken into the field, the machine and running gear can be quickly separated for loading into a vehicle. The 255 can also be separated from the EZ-Latch running gear to access difficult-to-reach areas around the shop where a welder with full running gear/cylinder rack might not otherwise fit.
NOTE: EZ-Latch™ running gear comes in separate box and requires some assembly. Components assemble in three steps and include: cart with front caster wheels, cylinder tray with rear wheels and cylinder post.
The Multimatic® 255 runs on 208 to 575 volt input power, using Miller's Auto-Line™ technology that automatically detects input voltage. It comes complete with MIG welding gun, shielding gas regulator with hose, stick electrode holder and ground clamp. TIG welding kit is sold separately.
Processes
MIG (GMAW)
Pulsed MIG (GMAW-P
Stick (SMAW)
Flux Cored (FCAW)
DC TIG (DC GTAW)
DC Pulsed TIG (DC GTAW-P)
Features
Available for MIG, pulsed MIG, stick and DC TIG processes with the ability to fine-tune your settings.
Set weld parameters by selecting:
MIG (shown) wire and gas type, wire diameter and material thickness
Stick electrode type, electrode diameter and material thickness
DC Lift-Arc™ TIG remote on/off, tungsten diameter and material thickness
Save up to four programs for each process.
Deliver more productivity by eliminating need to manually set parameters.
Deliver consistent quality by welders of all skill levels with prequalified settings.
Minimize supervisor intervention.
Lower heat input for less distortion on thin materials and better puddle control on out-of-position welds.
Less spatter minimizes post weld grinding and rework, allowing more welding time.
Perform welding applications that couldn't be done in the past.
Ideal for MIG welding aluminum and stainless steel.
Specs
This is a DC only machine. It cannot TIG weld Aluminum
Comes complete with
